*item may differ from images
Edelbrock part #2161-CP Performer 2-O intake manifold is designed for street 396-502 c.i.d. big-block Chevy V8's using general duty oval-port cylinder heads. The PN 2161-CP version comes with a brilliant Chrome plasma finish that is durable and easy to maintain.Will not fit under hood of Corvette without hood modifications. Will not fit "tall block" V8's. May be used with OEM or aftermarket carbs. Will fit 1965-90 oval port heads. Edelbrock's Patented Dual-plane, low-rise design with a 180-degree firing order greatly improves torque over a wide rpm range for excellent throttle response from off-idle through 5500rpm. This Performer intake manifold is ideal for passenger cars, trucks, 4x4s, tow vehicles and RVs.
Edelbrock Performer 2-O Manifold for 1965-90 B/B Chevy Oval Port Heads, Chrome Plasma 2161-CP
Specifications:
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Series | Performer |
| Vehicle Model | Chevrolet |
| 10 | Aluminum |
| 353 | No |
| 3390 | Performance |
| 6642 | Dual Plane |
| 6643 | 4.300 |
| 6644 | 4.850 |
| 6645 | 5.400 |
| 9063 | No |
| Finish | Chrome Plasma |
| Basic Operating RPM Range | Idle-5500 |
| EGR Port | No |
| Flange Type | 4150 |
| Description_ABR | Intake Mnfld |
| Description_INV | Performer BBC Intake Manifold Oval Port |
| Description_LAB | Performer 2-O Manifold for 1965-90 B/B Chevy Oval Port Heads, Chrome Plasma |
| Description_DES | Performer 2-O Manifold for 1965-90 B/B Chevy Oval Port Heads, Chrome Plasma |
| Description_SHP | None |
| Description_ASM | Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L) |
| Description_EXT | Edelbrock Performer 2-0 Intake Manifold for 1965-90 Big-Block Chevrolet 396-502 Engines with Oval Port Heads with a beautiful Chrome Plasma finish. Accepts Either OEM 4-bbl or 4150-Style Square-Bore Carburetors. Non-EGR |
| Description_MKT | Edelbrock part #2161-CP Performer 2-O intake manifold is designed for street 396-502 c.i.d. big-block Chevy V8's using general duty oval-port cylinder heads. The PN 2161-CP version comes with a brilliant Chrome plasma finish that is durable and easy to maintain.Will not fit under hood of Corvette without hood modifications. Will not fit "tall block" V8's. May be used with OEM or aftermarket carbs. Will fit 1965-90 oval port heads. Edelbrock's Patented Dual-plane, low-rise design with a 180-degree firing order greatly improves torque over a wide rpm range for excellent throttle response from off-idle through 5500rpm. This Performer intake manifold is ideal for passenger cars, trucks, 4x4s, tow vehicles and RVs. |
| Description_TRA | Recommended intake gasket: Edelbrock #7203. |
| Description_TRA | Use Edelbrock #8028 waterneck adapter for 1986 and later. |
| Description_TRA | Edelbrock choke plate #8961 included. |
| Description_TRA | Manifold height: A-4.300", B-5.400" |
| Description_TRA | Carb pad height: 4.85" |
| Description_TRA | Carb recommendations: Stock 4-Bbl use choke rod #9179 if needed, Edelbrock AVS2 or Performer Series 600-800cfm. Use bracket #8031 for 1972-78. |
| Description_TRA | Port exit dimensions: 1.70"w x 1.68" |
| Description_TRA | Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. |
| Description_TRA | Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
| Description_DEF | Engine Intake Manifold |
