*item may differ from images
Based on the wildly popular original Race Series carburetors, PROFORM's Black Race Series Carburetors include a Black Diamond coating for enhanced fuel cooling. Each carburetor is hand assembled and tested in the U.S. utilizing the PROFORM High-Flow Carburetor Main Body, durable billet metering blocks, high performance billet throttle baseplate, and lightweight aluminum fuel bowls. PROFORM Black Race Series Carbs include: (1) Adjustable High-Flow Aluminum Main Body with Screw-In Air Bleeds, Maximum Air Flow: No Air Horn, Choke Tower, or Choke Control, Uses standard service and tuning components! (2) Billet Throttle Base Plates: Adjustable Secondary Air Flow Cam Bracket, Solid Billet Construction, Manufactured in the U.S.A., Timed and Full Vacuum Tubes for Accessories and Tuning, Button Torx Head Throttle Plate Screws, Power Valve Blow Out Protection, Progressive Slip Link Mechanical Secondary Linkage, Serviceable Throttle Levers, and Ford Kickdown! (3) Billet Metering Blocks: Solid Billet Construction, Durable, No Warping or Porosity Problems, Changeable Idle Feed Restriction, Manufactured in the U.S.A.! (4) Aluminum Fuel Bowls: Lightweight Aluminum, Sight Glass Windows for easy float adjustment!
Proform 1050 CFM, Mechanical Secondary, Black & Purple 67305
Specifications:
| Feature/Benefit | Lightweight Aluminum Construction |
| Primary Power Valve (Hg) | 4.5 |
| Ford Kickdown Bracket Included | Yes |
| Needle & Seat | 130 |
| Height (IN) | 3.25 inch |
| Fuel Line Inlet Distance | 9-11/16 inch |
| Discharge Nozzle Size (Primary / Secondary) | .035 in. / .035 in. |
| Secondary Main Jet Size | 91 / .104 |
| Air Bleed Size (Inner High Speed) | 31 / 31 |
| Idle/High Speed Air Bleed Sizes | 70 / 31 |
| Primary Main Jet Size | 87.5 / .099 |
| Number of Barrels | 4 |
| Fuel | Gasoline |
| Air Bleed Size (Outer Idle) | 70 / 70 |
| Series | Black Race Series |
| Secondaries | Mechanical Secondaries |
| Base Plate Material | Billet Aluminum |
| Part Type | Carburetor |
| Booster Style | Down-Leg Boosters |
| Metering Block Material | Billet Aluminum |
| Calibration | Universal |
| Main Body Material | Lightweight Aluminum |
| Throttle Linkage | Universal |
| Fuel Inlet Thread | 7/8-in. x20 |
| Fuel Inlet | Dual |
| Flange Style | Square Bore |
| Finish | Black Diamond Finish |
| Emissions | 49 State Legal |
| EGR | Without EGR |
| Color | Black Diamond Finish |
| Choke | No Choke |
| CFM | 1050 CFM |
| Category | Carbs |
| Material | Aluminum |
| Air Bleeds Included | Yes |
| Air Bleed Material | Brass |
| 4708 | No |
| 6444 | 1.75 |
| 356 | 4 |
| 835 | 0.25 |
| 30 | No |
| 574 | No |
| 6443 | 1.875 |
| 4234 | Yes |
| 765 | 0.875 |
| 3390 | Performance |
| 353 | Yes |
| 4265 | Nitrophyl |
| 1968 | 4150 & 8090 |
| 4235 | Manual |
| 878 | Yes |
| 621 | Aluminum |
| 614 | 3.25 |
| 1385 | Black |
| 1428 | 5.25 |
| 1427 | 5.25 |
| 857 | 4 |
| 6440 | 0.25 |
| 6431 | Yes |
| 6442 | 0.1085 |
| 6441 | 0.102 |
| 1271 | Yes |
| 8783 | Square/4150 |
| 9324 | Mechanical |
| Description_ABR | Carburetor |
| Description_SHO | Carburetor 1050 CFM |
| Description_INV | Carb |
| Description_INV | Blk Race Series |
| Description_INV | 1050 CFM Mech Sec |
| Description_DEF | Carburetor |
| Description_ASC | Black Race Series Carburetor |
| Description_ASC | 1050 CFM, Mechanical Secondary, Black & Purple |
| Description_LAB | PROFORM Black Race Series Carburetor, 1050 CFM, Aluminum, Mechanical Secondary |
| Description_DES | Black Race Series Carburetor |
| Description_DES | 1050 CFM, Mechanical Secondary, Black & Purple |
| Description_EXT | Engine Carburetor |
| Description_EXT | Black Race Series Model |
| Description_EXT | 1050 CFM Dual Inlet 4-Barrel With Mechanical Secondaries |
| Description_EXT | Square Type Bore Mount |
| Description_EXT | Features Down-Leg Boosters and Black Diamond Finish |
| Description_EXT | No Choke |
| Description_EXT | Assembled With 100% New Components |
| Description_EXT | Sold Each |
| Description_MKT | Based on the wildly popular original Race Series carburetors, PROFORM's Black Race Series Carburetors include a Black Diamond coating for enhanced fuel cooling. Each carburetor is hand assembled and tested in the U.S. utilizing the PROFORM High-Flow Carburetor Main Body, durable billet metering blocks, high performance billet throttle baseplate, and lightweight aluminum fuel bowls. PROFORM Black Race Series Carbs include: (1) Adjustable High-Flow Aluminum Main Body with Screw-In Air Bleeds, Maximum Air Flow: No Air Horn, Choke Tower, or Choke Control, Uses standard service and tuning components! (2) Billet Throttle Base Plates: Adjustable Secondary Air Flow Cam Bracket, Solid Billet Construction, Manufactured in the U.S.A., Timed and Full Vacuum Tubes for Accessories and Tuning, Button Torx Head Throttle Plate Screws, Power Valve Blow Out Protection, Progressive Slip Link Mechanical Secondary Linkage, Serviceable Throttle Levers, and Ford Kickdown! (3) Billet Metering Blocks: Solid Billet Construction, Durable, No Warping or Porosity Problems, Changeable Idle Feed Restriction, Manufactured in the U.S.A.! (4) Aluminum Fuel Bowls: Lightweight Aluminum, Sight Glass Windows for easy float adjustment! |
| Description_FAB | Lightweight Aluminum Construction |
