*item may differ from images
Edelbrock part #2893 Super Victor 440 Max Wedge intake manifold is designed for 413-440-500+ RB with Max Wedge heads and 4500 Series carburetors. This intake manifold is designed to fit 1962-64 Max Wedge heads or the Edelbrock Victor Max Wedge cylinder heads #77939 and #77949 for maximum performance. For competition and high-rpm Chrysler V8's, the Super Victor 440 has an all-new runner design that delivers maximum power from 3500 to 8000 rpm in drag race applications. The manifold port exits are CNC machined to 1.30" x 2.58". Edelbrock part #7798 valley cover is required when used with Edelbrock Victor Series cylinder heads.
Edelbrock Engine Intake Manifold 2893
Specifications:
| Finish | Satin |
| Vehicle Model | Chrysler |
| EGR Port | No |
| Rear Maximum Height | 6.400 |
| Material | Aluminum |
| Gasket Or Seal Included | No |
| Front Maximum Height | 6.400 |
| CNC Ported | Yes |
| Grade Type | Performance |
| Single Or Dual Plane Type | Single |
| Basic Operating RPM Range | 3500-8000 |
| Center Maximum Height | 6.400 |
| Flange Type | 4500 |
| Series | Victor |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Description_ABR | Intake Mnfld |
| Description_INV | Super Victor Chrysler 440 Max Wedge Dom |
| Description_LAB | Super Victor Chrysler 440 Max Wedge Intake Manifold for 4500 Series Carb |
| Description_ASM | Chrysler:Big-Block RB-Series:413 (6.8L)/426 (7.0L)/440 (7.2L) |
| Description_EXT | Edelbrock Super Victor 440 Max Wedge Intake Manifold with 4500 Series Carb for Chrysler 413-426-440 Big-Block V8 |
| Description_MKT | Edelbrock part #2893 Super Victor 440 Max Wedge intake manifold is designed for 413-440-500+ RB with Max Wedge heads and 4500 Series carburetors. This intake manifold is designed to fit 1962-64 Max Wedge heads or the Edelbrock Victor Max Wedge cylinder heads #77939 and #77949 for maximum performance. For competition and high-rpm Chrysler V8's, the Super Victor 440 has an all-new runner design that delivers maximum power from 3500 to 8000 rpm in drag race applications. The manifold port exits are CNC machined to 1.30" x 2.58". Edelbrock part #7798 valley cover is required when used with Edelbrock Victor Series cylinder heads. |
| Description_TRA | Mopar Performance P/N P5249643, Fel-Pro #1218 or equivalent 2.63" x 1.34" for an area of 3.52 sq. inches. Custom gasket trimming is needed if larger area is desired. |
| Description_TRA | Carb recommendations: Use appropriate 4500 Series racing carburetor |
| Description_TRA | Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. |
| Description_TRA | Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
| Description_DEF | Engine Intake Manifold |
