Our new Edelbrock #61189 Victor Jr. cylinder head is designed for high output 650+ hp Chrysler 426-572 HEMI engines. They feature fully CNC'd combustion chambers and CNC blended seats for optimal air flow performance. This cylinder head also feature a revised exhaust valve angle to accommodate larger intake valves. They also feature brass tubes installed in exhaust pushrod holes to allow maximum clearance with minimal port intrusion.
Edelbrock Engine Cylinder Head 61189
Specifications:
| Quantity | Sold Individually |
| Valve Stem Diameter | 0.3125 |
| Valve Included | Yes |
| Combustion Chamber Volume | 170 |
| CNC Ported | Yes |
| Exhaust Port Location | Standard |
| Seat Angle | Exhaust 45 deg/Intake 45 |
| Exhaust Runner Volume | 105 |
| Construction Type | Bare With Valves |
| Exhaust Valve Diameter | 1.94 |
| Head Casting Number | N/A |
| Valve Springs Included | No |
| Guide Material | Manganese Bronze |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Seat Material | Ductile Iron |
| Intake Valve Diameter | 2.320 |
| Valve Angle | Exhaust (Tipped) 1.5-21.5 deg/Intake Stock |
| Guide Plates Included | No |
| Intake Runner Volume | 245 |
| EGR Port | No |
| Series | Victor Jr. |
| Material | Aluminum |
| Family | Victor Jr. |
| Retainer Included | No |
| Grade Type | Performance |
| Deck Thickness | 0.625 |
| Description_ABR | Cyl. Head |
| Description_INV | Edelbrock HEMI GEN II Cylinder Head |
| Description_LAB | Victor Jr Gen II HEMI Chrysler Cylinder Head CNC W/ Valves |
| Description_ASM | Chrysler:Big-Block Gen II HEMI:426 (7.0L) |
| Description_EXT | Our new Edelbrock #61189 Victor Jr. Cylinder Heads are designed for high output 650+ hp Chrysler 426-572 HEMI engines. Fully CNC'd combustion chambers and CNC blended seats for optimal air flow performance. |
| Description_MKT | Our new Edelbrock #61189 Victor Jr. cylinder head is designed for high output 650+ hp Chrysler 426-572 HEMI engines. They feature fully CNC'd combustion chambers and CNC blended seats for optimal air flow performance. This cylinder head also feature a revised exhaust valve angle to accommodate larger intake valves. They also feature brass tubes installed in exhaust pushrod holes to allow maximum clearance with minimal port intrusion. |
| Description_TRA | Victor Jr. CNC cylinder heads #61189 are shipped with reamed and machined valve stem guides, as well as a valve job to match the included intake and exhaust valves (valves not installed). Customer must supply their own valve springs, retainers, valve stem seals and valve locks. |
| Description_TRA | Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat. |
| Description_DEF | Engine Cylinder Head |
