Edelbrock part #29145 Victor E-Tec EFI intake manifold is a Vortec/E-Tec version of our popular Victor E 23 degree EFI intake manifold. This manifold features a similar deep plenum and tapered cross-sections like the Victor E 23 degree and is compatible with square-bore throttle bodies. This intake manifold is one inch shorter than the existing Super Victor E-Tec EFI #29135. It also has provisions for water bypass so it can be used on Vortec engine blocks and accepts OEM alternator brackets.
Edelbrock Edelbrock Victor E-Tec EFI Intake Manifold for Chevrolet 262-400 Small-Block V8 29145
Specifications:
| Front Maximum Height | 4.580 |
| Series | Victor |
| Vehicle Model | Chevrolet |
| EGR Port | No |
| Material | Aluminum |
| Single Or Dual Plane Type | Single |
| Rear Maximum Height | 4.580 |
| Center Maximum Height | 4.580 |
| Flange Type | 4150 |
| CNC Ported | No |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Grade Type | Performance |
| Basic Operating RPM Range | 2500-8000 |
| Finish | Satin |
| Gasket Or Seal Included | No |
| Description_ABR | Intake Mnfld |
| Description_INV | Victor E-Tec/ Vortec Intake Manifold EFI |
| Description_LAB | Victor E-Tec EFI Small Block Chevy Intake Manifold |
| Description_ASM | Chevrolet:Small-Block Gen I Vortec |
| Description_EXT | Edelbrock Victor E-Tec EFI Intake Manifold for Chevrolet 262-400 Small-Block V8 |
| Description_MKT | Edelbrock part #29145 Victor E-Tec EFI intake manifold is a Vortec/E-Tec version of our popular Victor E 23 degree EFI intake manifold. This manifold features a similar deep plenum and tapered cross-sections like the Victor E 23 degree and is compatible with square-bore throttle bodies. This intake manifold is one inch shorter than the existing Super Victor E-Tec EFI #29135. It also has provisions for water bypass so it can be used on Vortec engine blocks and accepts OEM alternator brackets. |
| Description_TRA | Recommended intake gasket: Edelbrock #7235 or GM #89017465 |
| Description_TRA | Carb pad height: 6.77" |
| Description_TRA | Port exit dimensions: 1.14"x 2.20" |
| Description_TRA | Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. |
| Description_TRA | Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
| Description_TRA | Sealant must be used on intake bolt threads if the threads extend into lifter valley or coolant passage. |
| Description_TRA | NPT/Pipe thread fittings require the use of Teflon tape or paste on threads to ensure proper seal. |
| Description_TRA | DO NOT OVERTIGHTEN NPT/Pipe fittings, this may cause the aluminum to crack around the fitting boss. NPT/Pipe thread is a tapered thread. |
| Description_TRA | Carburetor size (CFM) should be selected based on your specific engine combination. |
| Description_TRA | To ensure maximum performance and a proper seal, Edelbrock gaskets which are specifically designed and manufactured for use with Edelbrock parts must be used. |
| Description_DEF | Engine Intake Manifold |
