*item may differ from images
This Edelbrock cylinder head kit part #2240 is designed to include everything needed to successfully install a set of Edelbrock heads without having to hunt down the correct components. This will save the customer time and money and will give peace of mind knowing the correct items were chosen by our own Edelbrock Technical Staff.
Edelbrock Edelbrock Complete Small Block Chevy E-Street Cylinder Heads with Install kit 2240
Specifications:
| Valve Spring Diameter | 1.46 |
| Guide Plate Material | Hardened Steel |
| Intake Valve Diameter | 2.02 |
| Valve Angle | 23 |
| Quantity | Set of 2 |
| Deck Thickness | 0.5625 |
| Combustion Chamber Volume | 64 |
| Intake Runner Volume | 185 |
| CNC Ported | No |
| Rotor Center Bore Inside Diameter | Straight |
| Exhaust Valve Diameter | 1.60 |
| EGR Port | No |
| Family | E-Street |
| Guide Plates Included | Yes |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Seat Material | Ductile Iron |
| Construction Type | Complete |
| Valve Springs Included | Yes |
| Guide Material | Manganese Bronze |
| Valve Stem Diameter | 0.3438 |
| Horsepower | 300-400 |
| Push Rod Diameter | (Suggested) 0.3125 |
| Valve Spring Maximum Lift | 0.550 |
| Rocker Arm Stud Diameter | 0.375 |
| Seat Angle | Exhaust 45 deg/Intake 45 |
| Exhaust Port Location | Standard |
| Exhaust Runner Volume | 60 |
| Camshaft Type | Flat Tappet |
| Grade Type | Performance |
| Head Casting Number | N/A |
| Series | E-Street |
| Material | Aluminum |
| Retainer Included | Yes |
| Valve Included | Yes |
| Description_ABR | Cyl. Head |
| Description_INV | Edelbrock SBC Cylinder Head |
| Description_LAB | E-Street Cylinder Head #2240 SB Chevy 262-400, Hydraulic Flat Tappet |
| Description_ASM | Chevrolet:Small-Block Gen I:302 (4.9L)/327 (5.4L)/350 (5.7L)/400 (6.6L) |
| Description_EXT | Edelbrock Complete Small Block Chevy E-Street Cylinder Heads with Install kit |
| Description_MKT | This Edelbrock cylinder head kit part #2240 is designed to include everything needed to successfully install a set of Edelbrock heads without having to hunt down the correct components. This will save the customer time and money and will give peace of mind knowing the correct items were chosen by our own Edelbrock Technical Staff. |
| Description_TRA | Designed for use with Hydraulic Flat Tappet Camshafts .550" max lift. (NOT Compatible with Hydraulic Roller Camshafts) |
| Description_TRA | Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat. |
| Description_TRA | Requires hardened pushrods. |
| Description_DEF | Engine Cylinder Head |
