The Edelbrock 1410 Marine Series 750 CFM electric choke carburetor is a precisely tuned, quality-built carburetor that can handle the harsh abuse only a marine environment can inflict. Several characteristics make the 1410 Marine Series 750 CFM electric choke carburetor an outstanding marine performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The lightweight all-aluminum body features a two-piece body that is iridited and assembled with PTFE-coated shafts and pump arm for maximum protection. The simple tub-type bowls and rear-pivot floats all contribute to a carburetor that's reliable, user-friendly and is easily tunable for trouble-free operation.
Edelbrock Carburetor 1410
Specifications:
| Choke Type | Electric |
| Finish | Zinc-Dichromate |
| Body Height | 3.25 |
| Secondary Jet Diameter | 0.107 |
| Condition | New |
| RGL | WARNING: This product can expose you to Zinc, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Spring Force | 5" Hg (Orange) |
| Bore Diameter | Primary Bore 1.69; Secondary Bore 1.69 |
| Booster Type | annular |
| Metering Rod Size | .071 x .047 |
| Barrel Quantity | 4 Barrel |
| Series | Marine |
| Material | Aluminum |
| Primary Jet Diameter | 0.113 |
| Main Venturi Diameter | 1.44 |
| EGR Port | No |
| Gasket Or Seal Included | Yes |
| Maximum Flow Rating | 750 |
| Flange Shape | Square |
| Description_ABR | CARB |
| Description_INV | Edelbrock Marine 750 CFM Carburetor |
| Description_LAB | Marine Carb #1410 750 CFM With Electric Choke, Zinc-Dichromate Finish (Non-EGR) |
| Description_EXT | Edelbrock Marine Series 750 cfm, Square-Flange, Electric Choke Carburetor (non-EGR) |
| Description_MKT | The Edelbrock 1410 Marine Series 750 CFM electric choke carburetor is a precisely tuned, quality-built carburetor that can handle the harsh abuse only a marine environment can inflict. Several characteristics make the 1410 Marine Series 750 CFM electric choke carburetor an outstanding marine performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The lightweight all-aluminum body features a two-piece body that is iridited and assembled with PTFE-coated shafts and pump arm for maximum protection. The simple tub-type bowls and rear-pivot floats all contribute to a carburetor that's reliable, user-friendly and is easily tunable for trouble-free operation. |
| Description_TRA | Edelbrock carburetors are not calibrated for or compatible with alcohol, race or E85 pump fuel. The use of alcohol or E85 in your Edelbrock carburetor will damage your carburetor and void your warranty. These fuels can also damage other fuel system components, unless specifically designed for use with alcohol fuels |
| Description_TRA | The use of a new fuel filter between the fuel pump and carburetor is required. Failure to do so will void the manufacturer's warranty of the carburetor |
| Description_TRA | Edelbrock Performer Series carburetors are not for computer-controlled applications. That includes some 1981 & later GM vehicles with Q-Jet carburetor and some 1981 & later Ford vehicles with automatic overdrive (AOD) transmissions |
| Description_DEF | Carburetor |
