Transverse Flow design. Transverse flow mufflers were originally designed for GM F-Body Camaros and Firebirds. On these vehicles they were mounted behind the rear axle and were parallel to the axle. This muffler can also be used to create custom systems on other vehicles. Single 3" Offset Inlet/ Dual 2.5" Offset Outlets. The inlet and one outlet are on one end of the muffler, and the second outlet is on the opposite end. Reversible design for installation flexibility. High-quality T-304 austenitic stainless steel will never rust. 100% welded construction for strength. Free Flow design for improved performance. High-temperature continuous-filament fiber (CFF) acoustic material for sound control. Natural mill finish can be brushed or polished prior to installation. Best of all, it's made in the USA and backed by BORLA'S Million-Mile warranty. Just what you'd expect from the world's most experienced (and most winning) exhaust brand.
Borla Specialty Muffler - Un-Notched Neck 40474
Specifications:
| Body Height | 5.500 in. |
| Outlet Outside Diameter | 3.000 in. |
| Title Extended | Specialty Muffler Transverse Flow 3 in. Single Inlet/ 2.5 in. Dual Outlet 5.5 in. x 10.25 in. Oval x 19 in. Long Body Part # 40474 |
| Tip / Outlet Finish | N/A |
| Shape | Oval |
| Prop 65 Yes/No | Yes |
| Prop 65 (C, R or CR) | CR |
| Prop 65 - Short Label | Proposition 65 Warning.JPG |
| Prop 65 - Long Label | WARNING: This product in the physical form it is sold does not present a hazard. However, operations including, but not limited to welding, brazing, or thermal cutting can expose you to chemicals including Chromium, Nickel, Cobalt, Arsenic, Cadmium and Lead which are known to the State Of California to cause cancer, birth defects and other reproductive harm. For more information go towww.P65Warnings.ca.gov |
| Overall Length | 24.000 in. |
| Outlet Type | Dual Outlet |
| Outlet Position | Dual Rear |
| Off Road Use Only | No |
| Body Length | 19.000 in. |
| Muffler Count | 2 |
| Material | T-304 Stainless Steel |
| Main Piping Diameter | 3.000 in. |
| Inlet Type | Single Offset |
| Inlet Position | Offset |
| Inlet Outside Diameter | 3.000 in. |
| Inlet Connection Type | Pipe |
| Grade Type | Performance |
| Construction | All Welded |
| Body Width | 10.250 in. |
| Title | Specialty Muffler Transverse Flow 3 in. Single Inlet/ 2.5 in. Dual Outlet 5.5 in. x 10.25 in. Oval x 19 in. Long Body |
| Description_SHO | Transverse Muffler |
| Description_INV | BORLA Transverse Muffler |
| Description_DEF | Exhaust Muffler |
| Description_DES | Specialty Muffler - Un-Notched Neck |
| Description_ASM | Specialty Muffler - Transverse Flow - Single 3" Offset Inlet/ Dual 2.5" Offset Outlets (One Outlet On Same End As Inlet And One Outlet On Opposite End) 6" x 10.25" Oval x 19" Long Body 24" Overall Length. Universal Part. Reversible Design. |
| Description_EXT | Specialty Transverse Flow Muffler - 3" Offset Inlet/ Dual 2.5" Offset Outlets 6" x 10.25" Oval x 19" Long Body 24" Overall Length. Universal Part. Reversible Design. |
| Description_MKT | Transverse Flow design. Transverse flow mufflers were originally designed for GM F-Body Camaros and Firebirds. On these vehicles they were mounted behind the rear axle and were parallel to the axle. This muffler can also be used to create custom systems on other vehicles. Single 3" Offset Inlet/ Dual 2.5" Offset Outlets. The inlet and one outlet are on one end of the muffler, and the second outlet is on the opposite end. Reversible design for installation flexibility. High-quality T-304 austenitic stainless steel will never rust. 100% welded construction for strength. Free Flow design for improved performance. High-temperature continuous-filament fiber (CFF) acoustic material for sound control. Natural mill finish can be brushed or polished prior to installation. Best of all, it's made in the USA and backed by BORLA'S Million-Mile warranty. Just what you'd expect from the world's most experienced (and most winning) exhaust brand. |
| Description_FAB | Transverse flow design, originally designed for F-Body Camaro and Firebirds |
| Description_FAB | Universal muffler. Reversible design. |
| Description_FAB | Alternate muffler with Notched necks is 400498, use band clamps 18325 & 18330. |
| Description_FAB | Un-Notched necks are designed for weld in installation. If clamping, use band clamps 18004 & 18006. |
