Bilstein M 9200 (Coil Carrier) is designed specifically for professional off-road competition. M 9200 (Coil Carrier) utilize a fully adjustable dual rate spring hardware system that will compliment a wide array of industry standard 2.5 inch ID coilover springs. This coil carrier will not provide damping, but will sustain the weight of the vehicle at the adjusted ride height. These coil carriers are sold by length and are for custom applications. M 9200 (Coil Carrier) offers the ability to efficiently adjust spring rates to achieve the optimum performance.
Bilstein M 9200 (Coil Carrier) - Suspension Shock Absorber 33-243559
Specifications:
| PartType | Shocks / Struts |
| Body Diameter (ID) | 46mm |
| Collapsed Length (MM) | 546.1 |
| Extended Length (IN) Rounded | 36 |
| Spring Seat Included | No |
| Lower Mount Type | Eye .5x1.5in |
| Collapsed Length (IN) | 21.50 |
| Mount Type | Eye-to-Eye |
| Body Design | Threaded Body (Coilover) |
| Collapsed Length (IN) Rounded | 22 |
| Compression @0.52m/s | Coil Carrier No Valving |
| Internal Design | Monotube |
| Reservoir | Yes |
| Boot Included | N/A |
| Extended Length (IN) | 35.50 |
| Optional Reservoir Clamp | N/A |
| Series | M 9200 (Coil Carrier) |
| Upper Mount Type | Eye .5x1.5in |
| Extended Length (MM) | 901.7 |
| Title | Bilstein Shock Absorbers |
| Finish | Zinc Plated |
| Rebound @0.52m/s | Coil Carrier No Valving |
| Prop 65 (Y/N) | Y |
| Segment | Motorsports |
| Prop 65 - Short Label | WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov |
| Description_FAB | Designed to hold the coils in place |
| Description_FAB | Designed to hold the coils in place |
| Description_SHO | Shock |
| Description_INV | 46mm Coil-Carrier, 14", 9200 Series |
| Description_DEF | Suspension Shock Absorber |
| Description_LAB | M 9200 (Coil Carrier) - Suspension Shock Absorber |
| Description_DES | M 9200 (Coil Carrier) - Suspension Shock Absorber |
| Description_ASM | No Applications |
| Description_EXT | 46mm Monotube Shock Absorber |
| Description_MKT | Bilstein M 9200 (Coil Carrier) is designed specifically for professional off-road competition. M 9200 (Coil Carrier) utilize a fully adjustable dual rate spring hardware system that will compliment a wide array of industry standard 2.5 inch ID coilover springs. This coil carrier will not provide damping, but will sustain the weight of the vehicle at the adjusted ride height. These coil carriers are sold by length and are for custom applications. M 9200 (Coil Carrier) offers the ability to efficiently adjust spring rates to achieve the optimum performance. |
| Description_FAB | 46mm monotube design |
