Bilstein B8 6100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUV's with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing an adjustable ride height range of 0-3 inches (depending on application). The B8 6100 (Ride Height Adjustable) utilizes a large 60mm digressive piston. This will provide a smoother ride while offering more control over rough terrain. The B8 6100 (Ride Height Adjustable) will provide increased durability and heat dissipation, making them perfect for vehicles subjected to rugged roads and harsh conditions.
Bilstein B8 6100 (Ride Height Adjustable) - Suspension Shock Absorber 24-322669
Specifications:
| PartType | Shocks / Struts |
| Series | B8 6100 (Ride Height Adjustable) |
| Collapsed Length (IN) | 14.42 |
| Body Design | Snap Ring Grooved Body (Coilover) |
| Adjustable Damping | Non-Adjustable |
| Extended Length (MM) | 468.0 |
| Internal Design | Monotube |
| Reservoir | No |
| Collapsed Length (MM) | 366.2 |
| Finish | Zinc Plated |
| Upper Mount Type | Stem |
| Prop 65 - Short Label | WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov |
| Prop 65 (Y/N) | Y |
| Boot Included | No Boot Supplied or Needed |
| Body Diameter (ID) | 60mm |
| Spring Seat Included | Yes |
| Lower Mount Type | Eye 16mm |
| Extended Length (IN) | 18.43 |
| Title | Bilstein Shock Absorbers |
| Segment | Light Truck |
| Description_FAB | 60mm digressive piston improves ride comfort and control over rough terrain |
| Description_FAB | Large 60mm body for increased oil capacity, cooling, and long-term durability |
| Description_SHO | Shock |
| Description_DEF | Suspension Shock Absorber |
| Description_DES | B8 6100 (Ride Height Adjustable) - Suspension Shock Absorber |
| Description_EXT | 60mm Monotube Shock Absorber |
| Description_INV | Nissan Titan XD Diesel; '16-; F; B8 6100 |
| Description_LAB | B8 6100 (Ride Height Adjustable) - Suspension Shock Absorber |
| Description_ASM | Nissan TITAN XD 2024-2016 |
| Description_MKT | Bilstein B8 6100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUV's with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing an adjustable ride height range of 0-3 inches (depending on application). The B8 6100 (Ride Height Adjustable) utilizes a large 60mm digressive piston. This will provide a smoother ride while offering more control over rough terrain. The B8 6100 (Ride Height Adjustable) will provide increased durability and heat dissipation, making them perfect for vehicles subjected to rugged roads and harsh conditions. |
| Description_FAB | 60mm digressive piston improves ride comfort and control over rough terrain |
This Part Fits:
| Year | Make | Model | Submodel | Notes |
|---|---|---|---|---|
| 2016 | Nissan | TITAN XD | Platinum Reserve | |
| 2017 | Nissan | TITAN XD | Platinum Reserve | |
| 2018 | Nissan | TITAN XD | Platinum Reserve | |
| 2019 | Nissan | TITAN XD | Platinum Reserve | |
| 2020 | Nissan | TITAN XD | Platinum Reserve | |
| 2021 | Nissan | TITAN XD | Platinum Reserve | |
| 2022 | Nissan | TITAN XD | Platinum Reserve | |
| 2023 | Nissan | TITAN XD | Platinum Reserve | |
| 2024 | Nissan | TITAN XD | Platinum Reserve | |
| 2016 | Nissan | TITAN XD | PRO-4X | |
| 2017 | Nissan | TITAN XD | PRO-4X | |
| 2018 | Nissan | TITAN XD | PRO-4X | |
| 2019 | Nissan | TITAN XD | PRO-4X | |
| 2020 | Nissan | TITAN XD | PRO-4X | |
| 2021 | Nissan | TITAN XD | PRO-4X | |
| 2022 | Nissan | TITAN XD | PRO-4X | |
| 2023 | Nissan | TITAN XD | PRO-4X | |
| 2024 | Nissan | TITAN XD | PRO-4X | |
| 2016 | Nissan | TITAN XD | S | |
| 2017 | Nissan | TITAN XD | S | |
| 2018 | Nissan | TITAN XD | S | |
| 2019 | Nissan | TITAN XD | S | |
| 2020 | Nissan | TITAN XD | S | |
| 2021 | Nissan | TITAN XD | S | |
| 2022 | Nissan | TITAN XD | S | |
| 2023 | Nissan | TITAN XD | S | |
| 2016 | Nissan | TITAN XD | SL | |
| 2017 | Nissan | TITAN XD | SL | |
| 2018 | Nissan | TITAN XD | SL | |
| 2019 | Nissan | TITAN XD | SL | |
| 2020 | Nissan | TITAN XD | SL | |
| 2021 | Nissan | TITAN XD | SL | |
| 2016 | Nissan | TITAN XD | SV | |
| 2017 | Nissan | TITAN XD | SV | |
| 2018 | Nissan | TITAN XD | SV | |
| 2019 | Nissan | TITAN XD | SV | |
| 2020 | Nissan | TITAN XD | SV | |
| 2021 | Nissan | TITAN XD | SV | |
| 2022 | Nissan | TITAN XD | SV | |
| 2023 | Nissan | TITAN XD | SV | |
| 2024 | Nissan | TITAN XD | SV |
