*item may differ from images
Edelbrock #88150 Water Pump Corvette SBC 1984-91 short pump ideal to prevent overheating in street rods and street machines, as well as in tow rigs and motorhomes. Using state-of-the-art racing technology, Edelbrock has designed these "super cooling" Water Pumps to provide maximum flow, maximum pressure and equal distribution to both sides of the block within 1%. Available for most popular applications, these high performance pumps flow in only one direction for optimum efficiency. The casting's computer-designed internal passages and precision powdered metal impeller produce the maximum flow rate possible.
Edelbrock Engine Water Pump 88150
Specifications:
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Fan Clutch Included | No |
| Mounting Hole Quantity | 4 |
| Impeller Vane Quantity | 6 |
| Casting Number | 8815 |
| Housing Material | Aluminum |
| Impeller Material | Powdered Metal |
| Installation Warnings | Yes |
| Mounting Hardware Included | No |
| Hub Hole Quantity | 6 |
| Includes Back Housing | Yes |
| Pulley Included | No |
| Thermostat And Housing Included | No |
| Impeller Rotation | Reverse |
| Hub Height | 5.800 |
| Water Pump Drive Type | V-Belt |
| Related Cooling Fan Components | No |
| Outlet Quantity | 1 |
| Description_ABR | Water Pump |
| Description_INV | Water Pump Corvette SBC 1984-91 |
| Description_LAB | Water Pump for Small-Block 1984-91 350 c.i.d. Corvettes in Satin Finish (Short) |
| Description_ASM | Chevrolet:Small-Block Corvette:350 (5.7L) |
| Description_EXT | Edelbrock #88150 Water Pump Corvette SBC 1984-91 Short Pump Ideal To Prevent Overheating In Street Rods And Street Machines |
| Description_MKT | Edelbrock #88150 Water Pump Corvette SBC 1984-91 short pump ideal to prevent overheating in street rods and street machines, as well as in tow rigs and motorhomes. Using state-of-the-art racing technology, Edelbrock has designed these "super cooling" Water Pumps to provide maximum flow, maximum pressure and equal distribution to both sides of the block within 1%. Available for most popular applications, these high performance pumps flow in only one direction for optimum efficiency. The casting's computer-designed internal passages and precision powdered metal impeller produce the maximum flow rate possible. |
| Description_TRA | #88150 is a reverse rotation water pump for 1984-92 Corvettes with serpentine drive belt |
| Description_TRA | Not for LT-1 Corvettes. Polished Aluminum Water Pump #8825 fits the same applications as #88150 |
| Description_TRA | #88810 is a reverse rotation water pump for 1987-93 passenger cars and light duty trucks with serpentine drive belt. Not for Corvettes EnduraShine Coated Aluminum Water Pump #888104 and Polished Aluminum Water Pump #8891 fit the same applications as #88810 |
| Description_TRA | #88820 is a short leg pump for 1955-'68 passenger cars, light duty trucks, and 1969-'70 Corvettes with AFTERMARKET serpentine belt pulleys (reverse rotation) |
| Description_TRA | This pump is ideal for street rods with aftermarket serpentine belt pulleys. Polished Aluminum Water Pump #8892 fits the same applications as #88820 |
| Description_TRA | Installation is the same as for original equipment water pumps. Consult service manual for specific procedures, if necessary |
| Description_TRA | CAUTION: Be sure that fan bolts don't protrude through the hub so far that they hit the water pump housing |
| Description_TRA | NOTE: Removal of backing plate is not recommended, as there are no user serviceable parts in the water pump. If backing plate is removed, use conventional gasket sealer (not RTV silicone) on gasket. |
| Description_DEF | Engine Water Pump |
This Part Fits:
| Year | Make | Model | Submodel | Notes |
|---|---|---|---|---|
| 1984 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish | |
| 1985 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish | |
| 1986 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish | |
| 1987 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish | |
| 1988 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish | |
| 1989 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish | |
| 1990 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish | |
| 1991 | Chevrolet | Corvette | Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish,Short-Style; Reverse Rotation; 3/4 in. Pilot Shaft; 3/4 in. Ball/Ball Bearing; 5.80 in. Block To Hub Height; 1.54 in. Inlet Size; Satin Finish |
